üApplication Function
Measure bursting strength
Measure bursting strength
üOptional Accessories (to purchase separately)
uRS-232 Interface and computer software
uCompressed air is supplied by client
üStandards
ISO 2758, GB/T 454, QB/T 2679.8
| Item | Details |
| Power supply | AC 220V±10% 50 Hz, 100W (can be customized) |
| Working environment | 10~35℃, humidity £85% |
| Measuring range | 50~1600 kPa |
| Indicating accuracy | ±0.5% |
| Resolution | 0.1 kPa |
| Oil speed | 95±5 ml/min |
| Required compressed air | 0.6-0.7 Mpa |
| Air pressure regulating | 0.15 Mpa |
| Sealing Property of hydraulic system | Upper limit 1 min Pressure drop <10% Pmax |
| Sampler diameter | Up loop Ø30.5±0.05 mm; Down loopØ33.1±0.05 mm |
| Built-in thermal printer | |
| Communication interface | RS-232 |
| Dimensions | 460(W)x320(D)x580(H) mm |
Net weight
|
56 kg
|
